Screenshot Capture in Phoenix LiveView Feedback Widget

I built a feedback widget that captures screenshots. One click, it grabs exactly what the user sees, uploads to S3, attaches it to the bug report. No page navigation, no browser extensions.

The Widget

Floating LiveComponent. Chat bubble in the bottom-right. Click it, fill out title/description/severity, optionally grab a screenshot, submit. Issue shows up in CodeMySpec with the screenshot attached.

It checks its own OAuth connection on mount. No CodeMySpec integration? Renders nothing. No hooks, no prop-drilling. Drop it in root.html.heex and forget about it.

sequenceDiagram
    participant U as User
    participant W as FeedbackWidget (LiveComponent)
    participant H as Colocated Hook (JS)
    participant HTI as html-to-image
    participant API as CodeMySpec API
    participant S3 as S3

    U->>W: Clicks "Capture Screenshot"
    W->>H: capture_start event
    H->>HTI: captureScreenshot()
    Note over HTI: Renders document.body to canvas
Filters out the widget itself
Patches fetch for SVG refs
    HTI-->>H: base64 PNG data URL
    H->>W: screenshot_captured event
    Note over W: Shows screenshot preview in form
    U->>W: Fills title, description, severity
    U->>W: Clicks Submit
    W->>API: presign_upload(filename, content_type)
    API-->>W: presigned S3 URL + s3_key
    W->>S3: PUT binary to presigned URL
    W->>API: create_issue(attrs, attachments: [s3_key])
    API-->>W: Issue created
    W-->>U: "Thanks for your feedback!"

The Screenshot Capture

The fun part. User clicks "Capture Screenshot" and the widget grabs exactly what's on screen. Not a browser API screenshot - a rendered-to-canvas capture of the DOM.

The JavaScript

import { toCanvas } from "html-to-image";

export async function captureScreenshot() {
  const origFetch = window.fetch;
  window.fetch = function(input, init) {
    const url = typeof input === "string" ? input : input?.url || "";
    if (url.includes("%23") || url.includes("#")) {
      return Promise.resolve(new Response("", { status: 200 }));
    }
    return origFetch.call(this, input, init);
  };

  try {
    const canvas = await toCanvas(document.body, {
      pixelRatio: Math.min(window.devicePixelRatio, 2),
      skipFonts: true,
      width: window.innerWidth,
      height: window.innerHeight,
      style: {
        transform: `translate(-${window.scrollX}px, -${window.scrollY}px)`,
      },
      canvasWidth: window.innerWidth,
      canvasHeight: window.innerHeight,
      filter: (node) => {
        if (node.id === "cms-feedback") return false;
        return true;
      },
    });
    return canvas.toDataURL("image/png");
  } finally {
    window.fetch = origFetch;
  }
}

window.__captureScreenshot = captureScreenshot;

Three things I want to call out:

The fetch monkey-patch. html-to-image fetches every URL in the DOM, including SVG url(#id) refs. Those aren't real URLs. The library turns them into fetch requests that 404 and spam the console. The patch intercepts any fetch with # and returns an empty 200. Ugly, effective. Restored in finally.

Self-filtering. The filter callback skips node.id === "cms-feedback". The screenshot captures the page without the feedback form floating on top of it.

Scroll position. The style.transform offset accounts for scroll. Without it you capture the top of the page. With it you capture exactly the viewport the user is looking at.

The Colocated Hook

Phoenix 1.8 colocated hooks are one of my favorite features. The JS lives right in the template:

<script :type={Phoenix.LiveView.ColocatedHook} name=".CmsScreenshot">
  export default {
    mounted() {
      this.el.addEventListener("click", async (e) => {
        if (!e.target.closest("[data-capture-screenshot]")) return;
        this.pushEventTo(this.el, "capture_start", {});
        try {
          const dataUrl = await window.__captureScreenshot();
          this.pushEventTo(this.el, "screenshot_captured", { data: dataUrl });
        } catch (err) {
          console.error("Screenshot capture failed:", err);
          this.pushEventTo(this.el, "screenshot_captured", { data: null });
        }
      });
    },
  }
</script>

No separate JS file. No app.js registration. The hook lives where it's used. Listens for clicks on [data-capture-screenshot], calls the screenshot function, pushes the result back to the LiveComponent.

Two-event flow (capture_start then screenshot_captured) so the widget can show a spinner. Canvas rendering can take a second on complex pages.

The Upload Flow

Presigned S3 upload. The app server never touches the file:

defp upload_screenshot(scope, data_url) do
  with [_, base64] <- Regex.run(~r/^data:image\/png;base64,(.+)$/, data_url),
       {:ok, binary} <- Base.decode64(base64),
       {:ok, %{upload_url: url, s3_key: key}} <- Client.presign_upload(scope, "screenshot.png", "image/png") do
    case Req.put(url, body: binary, headers: [{"content-type", "image/png"}]) do
      {:ok, %Req.Response{status: status}} when status in 200..299 ->
        {:ok, %{"s3_key" => key, "filename" => "screenshot.png", "content_type" => "image/png", "size" => byte_size(binary)}}
      _ ->
        {:error, :upload_failed}
    end
  end
end

Decode base64 to binary. Get a presigned URL from CodeMySpec. PUT directly to S3. Issue gets the S3 key as a reference.

The Generator

Ships as a Mix generator:

$ mix cms_gen.feedback_widget

Three files:

feedback_widget.ex - the LiveComponent
codemyspec/client.ex - HTTP client for the API
screenshot.js - the capture logic

Drop the component in your root layout, install html-to-image, configure OAuth. Done.

Why I'm Proud of This

I've spent years reading bug reports that say "the button doesn't work." Now they say "the button doesn't work" plus a picture of exactly what the user was looking at. Gets you 80% of the way to reproducing the issue before you even open the code.

The colocated hook is what makes it feel clean. Before Phoenix 1.8, you'd have a JS file in app.js conceptually tied to a LiveView but physically somewhere else. Now I read the widget code and the hook is right there.
